Featured Products
CAL Controls 9500P Series Temperature Process Controller with Programmer
- Full PID auto-tuning process controller
- Total of 3 outputs, from 4-20mA, 0-5v, 0-10v, SSR drive, relay
- Input options: Thermocouple 2 or 3 wire PT100 0-50mV, 0-5V, 0-10V, 0-20mA, 4-20mA
- Alarms with 5 options
- Heat-cool operation
- Programmer operation
- Sleeve mounting for easy maintenance
- IP66 protection from front panel
- CE, UL & CSA approvals
- 3-year warranty
- Monitoring and configuration software option
- RS232/485 options, Modbus RTU protocol
Typical Application
In the example on the right, the load temperature is monitored by a temperature transducer/transmitter which provides a 4–20mA input signal to the controller. The 4–20mA output has been allocated to SP1 to drive an SCR power controller providing a phase angle controlled output to the heater.
Programmer Features:
- Up to 31 programs (profiles)
- Up to 126 segments
- Unlimited use of event outputs via the 2nd and 3rd outputs
- Copy/paste/edit/delete functions to simplify program building
- Call another program as a sub-program segment
- Up to 999 program loop cycles, or continuous loop cycling
- Hold back function to ensure the next segment is not started until the last segment reaches set-point
- 3 power fail recovery options, (hold, continue or reset)
- Front Panel Interrogation of the program position
- Memory usage indication during programming
- Front panel 'release from hold' function to run the program.
SIMATIC S7-1200 PLC
SIMATIC S7-1200 PLC Easily adapted to suit your needs
The SIMATIC S7-1200 micro PLC and the SIMATIC HMI Basic Panels feature SIMATIC STEP 7 Basic engineering software for simple-and-speedy programming, networking and commissioning. The micro PLC's central unit is fully compatible with a range of I/O and communications modules, providing flexible extension options. The system also offers a PROFINET interface for easy networking and communication between the engineering system, controllers, and HMI.
